Eclipse Demo Camp 2009 in Paris with Acceleo and OD

Next week, November 17th, come in Paris to see Eclipse Community and news of Eclipse projects.
I co-organise this event with Cedric Vidal , a very nice guy with lots of cool ideas on model driven and EMF, and we want to promote talks with live demos and few slides (I hate "slideware talks").
We success

Some very nice talks will be propose on Birt, XText, UI (with XWT and Wazaabi) and a "guess star" with an introduction of Mike Milinkovich (Executive Director of the Eclipse Fondation).


Jonathan Musset will talk about the new features of Eclipse Acceleo project. This demo has been shown at Eclipse Summit Europe and was very impressive by the quality of the template editor which is perhaps the best editor of Eclipse platform, just after JDT.




We will also make some demo of Obeo Designer, our Eclipse Modeling distribution with a new exciting tooling to create GMF designers without any Java code (during our demo, we will create from scratch a new nice designer).




Info on the Eclipse wiki page:
http://wiki.eclipse.org/Eclipse_DemoCamps_November_2009/Paris

Register on http://eclipsedemocampparis09.eventbrite.com/
or directly with this form:

Acceleo nominated at Eclipse Technology Awards

Acceleo project has been nominated for the Eclipse Award in the category "Best Open Source Eclipse-Based Developer Tool".
I really think Acceleo can win because it proposes some nice Eclipse tooling, but also because it proves a real community of users and contributors with an open development process.

Last year, it was EclEmma which won.

Icon set for post-ganymede version of Eclipse SCA

Hi,

I just work on some new icons for Eclipse SCA project.
I need some comments to choose which one need to be removed or changed.

On my point of view, it will be nicer than the v1.0 version because it will better fit Eclipse UI and icons style.

New global palette:

SCA Bindings:

SCA Implementations:

SCA Interfaces:


The new tree Editor:
The graphical Designer isn't ready because it uses old style for embedded icons.
For comment, you can use this bug report.

Eclipse 3.4 Ganymede: News and Noteworthy by projects

Eclipse Ganymede has just been released.

Here are list of new features of modeling projects:

• EMF 2.4
• EMF Query, Transaction, Validation 1.2
• Teneo 1.0
• CDO 1.0
• Net4j 1.0
• EMF Compare 0.8
• Ecore Tools 0.8

• GMF 2.1
• MDT 1.1 (OCL, EODM, UML2, XSD)

• ATL 2.0

There are other projects (like Jet, QVT-O, ...) but there haven't a News and Noteworthy page.

ATL 2

ATL v2 will be release very soon.
ATL is a model transformation engine based on MDA standard and Eclipse platform.
It can used for:
- interoperability between tools
- translate a model from a notation to another (for example: relational to uml)
- propose "different zooms" on a model (for example: global specification -> detailled specification -> global design -> ...)
- create any kind of bridge (for example: BPMN -> BPEL or BPMN -> SCA)

ATL 2 is provide some new exciting features:
- better completion on model elements
- virtual machin based on EMF
- better performance
- lots of bug fixes
- a clean updatesite
- integration inside Ganymede (Eclipse 3.4)
- and a new commercial support on http://www.atl-pro.com


See News and Noteworthy for more detail on ATL 2.

Eclipse SCA 1.0

After one year of work, Eclipse SCA 1.0 is ready.

This is a new project of Eclipse STP (Soa Tool Platform) for assembly of SOA applications.
To understand the goal of SCA standard (Service Component Architecture, available here), the easiest way is to use an example:
you have one GUI component (for exemple, C# based) named "A" and it need to communicate with one business component "B" write EJB and Java and with another external component "C" written in PHP and only accessible with WebService. With SCA, you just need to declare each component, a reference (required interface) on A (declare with C# interface), and two services on B and C.
The SCA server will automaticly translate protocols and API language to ensure everybody can communicate with everybody.
In a nutshell, SCA isn't a new middleware (it rely on existing middlewares or libraries). It's like Spring, but as a specification and for any protocols and languages.


The main feature of Eclipse SCA project is a nice designer. It's used color and shape very similar of official specification and it's based on GMF. I'm one of the commiters team of this project and the leader is Stephane Drapeau.

It will be bundle inside Ganymede (Eclipse 3.4).
You can test it and read this nice tutorial.

Statechart diagram generation

As a proof of concept, we create an Acceleo generator for UML2 Statechart diagram.
This generator has been made as a TopCased work (to be include, I hope, as a built-in TopCased generator).

Here is a nice flash demo: http://www.obeo.fr/download/transfert/capture1.htm

The source code generated uses Smuc framework, but it will be easy to target any standard technology (like C, Java, ...).
Thanks to Cedric Notot for all his work on this generator and who experiment new strategies for models validation with Acceleo.
